Ports

• PoE Ports : 24 × 10/100/1000 Mbps RJ45

• Uplink Ports : 2 × Gigabit RJ45

• SFP Ports : 2 × 1000 Mbps Fiber Ports

• Standards : IEEE 802.3 / 802.3u / 802.3ab / 802.3x

PoE Power

• PoE Standard : IEEE 802.3af / IEEE 802.3at

• Max Power per Port : Up to 30W

• Total PoE Budget : Up to 450W

Network Performance

• Switching Capacity : 54 Gbps

• MAC Address Table : 8K

• Forwarding Mode : Store-and-Forward

• Transmission Distance : Up to 100 meters

• Cable Type : Cat5e / Cat6 Ethernet Cable

Protection & Features

• Lightning Protection : 6KV

• Auto MDI/MDIX : Supported

• Flow Control : IEEE 802.3x

• Plug & Play : Supported

Electrical

• Power Input : 100-240V AC

• Frequency : 50 / 60 Hz

• Power Supply : Built-in SMPS

Environmental

• Operating Temperature : 0°C to 55°C

• Storage Temperature : -20°C to 70°C

• Humidity : 20% - 95% RH (Non-Condensing)

Physical Details

• Material : Metal Housing

• Dimensions : 44 × 19 × 4.5 cm

• Installation Type : Rack Mount (19\\\")
